ECS Agencies in T Cloud Public

Using Temporary Agency Tokens (also known as Metadata Service tokens) is the "gold standard" for security on T Cloud Public. It allows your ECS to authenticate without you ever hardcoding an AK/SK or password in your scripts.

The ECS "borrows" the permissions of an IAM Agency assigned to it.

Step 1: Create an IAM Agency

Before you can use tokens, you must give the ECS permission to act.

1. In the OTC Console, go to IAM > Agencies.
2. Create a new Agency:
   • Agency Type: Cloud Service.
   • Cloud Service: ECS.
   • Permissions: Add the DNS Administrator role (to allow the DNS challenge).
3. Go to your ECS instance settings and "Modify" the instance to associate it with this new Agency.

Step 2: Retrieve the Token via Metadata Service

Once the agency is attached, the ECS can talk to a local non-routable IP address (169.254.169.254) to get security credentials.

You can fetch a temporary token using curl from inside your ECS:

# Get the temporary security credentials
curl -s http://169.254.169.254/openstack/latest/securitykey

The response will contain a temporary Access, Secret, and SecurityToken.

Step 3: Using the Token

You can now use the security token to issue REST API call. Note that the token is a temporary AK/SK with Security Token. This means that you need to sign your request.

I am using this script script to issue REST API calls.

Usage: aksk_apicall [-h] [--metadata METADATA | --ak AK] [--sk SK] [--token TOKEN] [--version] {GET,PUT,POST,DELETE} url [body]_

Calls T Cloud Public API using AK/SK credentials

positional arguments:

• {GET,PUT,POST,DELETE} : REST API verb
• url : End-point URL
• body : JSON text body (if needed, usually for PUT or POST requests). Use @filename to read the body from filename.

options:

• -h, --help : show this help message and exit
• --metadata, -m METADATA : Retrieve credentials from the given MetadataURL
• --ak, --access-key, -a AK : Specified Access Key (or environment: OS_ACCESS_KEY)
• --sk, --secret-key, -s SK : Specified Secret Key (or environment: OS_ACCESS_SECRET)
• --token, --security-token, -t TOKEN : Specified Secret Key (or environment: OS_ACCESS_TOKEN)
• --version, -V : show program's version number and exit

Should work with Permanent and Temporary AK/SK pairs, if no authentication information is provided it will automatically retrieve it rom the previously mentioned Metadata URL.

Example use:

python3 curler.py GET https://dns.eu-de.otc.t-systems.com/v2/zones | jq .

Example use case

You can use this with certbot to issue Let's Encrypt for your VMs. You just need to implement a Manual Auth Hook to call the T Cloud Public DNS API to set-up the necessary ACME challenge strings.

A Small Heads-up

Using temporary tokens with Certbot is a bit "DIY" because most ACME clients (like acme.sh or lego) are hard-coded to look for static AK/SK environment variables. They don't always know how to handle the X-Security-Token header required for temporary credentials.

Still, this is the most secure way to handle automated renewals. Because standard ACME clients don't always natively "poll" the metadata service for the X-Security-Token, you need to use Certbot's Manual Hooks.

Using Terraform

All of this can be configured via Open Tofu.

Here's a complete example:

The Three Resources You Need

1. Create the Agency — using opentelekomcloud_identity_agency_v3:

The opentelekomcloud_identity_agency_v3 resource creates the agency and assigns roles in one block. The delegated_domain_name sets which cloud service is trusted (for ECS, use op_svc_ecs), and project_role defines the permissions.

resource "opentelekomcloud_identity_agency_v3" "ecs_agency" {
  name                 = "my-ecs-agency"
  description          = "Agency for ECS temporary credentials"
  delegated_domain_name = "op_svc_ecs"   # Trusts the ECS service

  project_role {
    project = "eu-de"                    # Your OTC project/tenant name
    roles   = ["OBS OperateAccess"]      # Replace with the roles you need
  }
}

2. Create the ECS VM — using opentelekomcloud_ecs_instance_v1:

The opentelekomcloud_ecs_instance_v1 resource manages the VM. The agency is assigned by name via the agency_name metadata field.

resource "opentelekomcloud_ecs_instance_v1" "my_vm" {
  name              = "my-server"
  image_id          = var.image_id
  flavor            = "s3.medium.2"
  vpc_id            = var.vpc_id
  availability_zone = "eu-de-01"
  key_name          = var.key_pair

  nics {
    network_id = var.network_id
  }

  # Assign the agency to this VM
  metadata = {
    agency_name = opentelekomcloud_identity_agency_v3.ecs_agency.name
  }

  depends_on = [opentelekomcloud_identity_agency_v3.ecs_agency]
}

3. Wire it together with depends_on to ensure the agency exists before the VM is created (shown above).

Important Notes

Permissions required: For agency creation, your Terraform user needs to have the corresponding IAM permissions (security admin), which are different from what's required to authorize via the console.

On the other hand, configuring an existing agency for an ECS only requires being an administrator or an IAM user with ECS permissions. This is a much lower bar — essentially anyone who can create or modify ECS instances can assign an already-existing agency to one.

If you have a separation-of-duties scenario where:

• A security/IAM admin creates and manages the agency (once, as a one-off)
• A developer/ops user just deploys VMs and assigns the agency

...then the developer only needs standard ECS permissions (ECS FullAccess or equivalent). They can reference the pre-existing agency by name in the metadata block without needing any IAM privileges at all:

resource "opentelekomcloud_ecs_instance_v1" "my_vm" {
  # ... standard ECS fields ...

  metadata = {
    agency_name = "my-existing-agency"   # Just a name reference, no IAM needed
  }
}

So in short: no IAM/security-admin permissions are needed just to attach an existing agency to a VM. That operation goes through the ECS API, not the IAM API.

delegated_domain_name for ECS: For ECS instances specifically, use "op_svc_ecs" as the service principal. The example from the docs uses "op_svc_cce" for CCE clusters — make sure you use the right one for ECS.

Role names: Use the exact IAM role names as they appear in the OTC console (e.g., "OBS OperateAccess", "Tenant Administrator", etc.). You can also use domain_role instead of project_role if you want domain-level (cross-project) permissions:

resource "opentelekomcloud_identity_agency_v3" "ecs_agency" {
  name                  = "my-ecs-agency"
  delegated_domain_name = "op_svc_ecs"

  domain_role = ["OBS Administrator"]   # Domain-level role
}

Why this is better:

• No Credentials on Disk: If your server is compromised, there are no permanent keys to steal.
• Automatic Rotation: The tokens expire automatically (usually after 24 hours), and the ECS service handles the rotation behind the scenes.
• Centralized Control: You can revoke the ECS's ability to edit DNS records instantly by removing the Agency from the IAM console, without touching the server.
• Audit Trail: T Cloud Public logs will show the Agency performing these actions, making it easy to track in Cloud Eye / Cloud Trace Service.
